Automatic garage doors have become an essential part of modern homes and commercial garages. They offer convenience, security, and enhanced functionality compared to traditional manual garage doors.

Materials

Aluminum Alloy: Light, strong, corrosion - resistant.

Stainless Steel: High corrosion resistance and hardness, e.g., 304 and 316 types.

Color - Coated Steel Plate: Low - cost, various colors, but less durable.

Crystal Sheet (PC): Transparent, impact - and weather - resistant.

Inquiry

Write a Review

Types of Automatic Garage Doors

Sectional Garage Doors - These are made up of several horizontal sections that are hinged together. When the door opens or closes, the sections roll up and over the garage ceiling in a curved path. Sectional doors are popular due to their smooth operation and ability to fit different garage openings. They also provide good insulation as the sections can be well-sealed.

Roller Garage Doors - Roller garage doors consist of a single sheet of material (usually steel or aluminum) that rolls up around a drum at the top of the garage opening. They are space-efficient as they take up less headroom when open compared to sectional doors. Roller doors can be a good choice for garages with limited vertical space.

Side-Hinged Garage Doors - Side-hinged garage doors operate like traditional hinged doors, swinging open on hinges attached to the side of the garage opening. They are often preferred for their simplicity and ease of manual operation in case of power failures. Some side-hinged doors can also be automated with the addition of an appropriate opener mechanism.

Advantages

Convenience - With an automatic garage door, you can open or close the door with just a push of a button, either from inside the garage using a wall-mounted control panel or from your vehicle using a remote control. This is especially convenient when you are arriving or leaving home with your hands full or in bad weather conditions.

Security - Automatic garage doors can be locked and unlocked automatically, and many models come with advanced security features such as encrypted remote controls, rolling code technology, and alarm systems. These features help to prevent unauthorized access to your garage and protect your vehicles and other belongings inside.

Enhanced Appearance - Modern automatic garage doors come in a variety of styles, colors, and finishes, allowing you to choose one that complements the overall look of your home or building. They can add a touch of elegance and sophistication to the exterior of your property.

PRODUCT Parameters

I. Dimensions
Height	Customizable, 2 - 5m for commercial (2 - 2.5m for small stores, 4 - 5m for large warehouses), 2 - 2.2m for residential garage doors.
Width	Customizable, 1 - 10m+ for commercial (1 - 3m for small shops, 8 - 10m for large mall unloading areas), 2.5 - 3.5m for residential garage doors.
II. Materials
Aluminum Alloy	Light, strong, corrosion - resistant.
Stainless Steel	High corrosion resistance and hardness, e.g., 304 and 316 types.
Color - Coated Steel Plate	Low - cost, various colors, but less durable.
Crystal Sheet (PC)	Transparent, impact - and weather - resistant.
III. Motor
Power	0.3 - 0.5kW for small (5 - 10m²), 0.5 - 0.75kW for medium (10 - 20m²), 1 - 2kW+ for large (>20m²) doors.
Speed	Varies, higher for fast - opening needs, lower for stability in residential garages.
Drive Mode	Chain (simple, high load, noisy) or Shaft (quiet, compact, lower load capacity).
IV. Operation
Opening Speed	0.2 - 0.3m/s for small, 0.15 - 0.2m/s for medium, 0.1 - 0.15m/s for large doors.
Closing Speed	Similar to opening, may be limited for safety.
Noise	60 - 70dB normally, can be lower with good design.
V. Safety
Anti - Pinch	Via infrared or pressure sensors, may rebound.
Anti - theft	Good with stainless/aluminum, plus locks and alarms.

Product description

Door Panel

The door panel is the main part of the garage door that provides the physical barrier. It can be made of various materials such as steel, aluminum, wood, or composite materials. The choice of material depends on factors like durability, appearance, and cost.

Motor and Opener System

The motor is the power source that drives the garage door to open and close. It is usually an electric motor with sufficient power to move the weight of the door panel. The opener system includes the motor, gears, and other mechanical components that work together to control the movement of the door. There are different types of openers, such as chain-driven, belt-driven, and screw-driven openers. Each has its own advantages in terms of noise level, speed, and durability.

Tracks and Rollers

Tracks are installed on the sides of the garage opening to guide the movement of the door panel. Rollers are attached to the door panel and run along the tracks, ensuring smooth and straight movement of the door. The quality of the tracks and rollers affects the overall operation and lifespan of the garage door.

Sensors and Safety Features

Most automatic garage doors are equipped with sensors to detect obstacles in the path of the door. Infrared sensors are commonly used to sense if there is anything in the way when the door is closing. If an obstacle is detected, the door will immediately stop and may even reverse direction to avoid crushing or damaging the obstacle. Additionally, there are safety edges on the bottom of the door that can also detect contact with an object and trigger the safety mechanism.

Door Panel

Motor and Opener System

Tracks and Rollers

Sensors and Safety Features

Maintenance

Regular Cleaning

It is important to clean the garage door regularly to remove dirt, dust, and debris that can accumulate on the door panel and affect its appearance and operation. Use a mild detergent and a soft cloth to wipe down the door, and make sure to clean the tracks and rollers as well.

Lubrication

The tracks, rollers, and moving parts of the garage door need to be lubricated periodically to ensure smooth operation. Use a suitable lubricant such as silicone spray or white lithium grease and apply it to the tracks, rollers, and hinges according to the manufacturer's instructions.

Inspection of Components

Regularly inspect the motor, opener system, tracks, rollers, and sensors for any signs of wear, damage, or malfunction. If you notice any problems, it is advisable to contact a professional garage door technician to have them repaired or replaced as soon as possible.

Conclusion

Automatic garage doors offer numerous benefits in terms of convenience, security, and aesthetics. By understanding their types, components, working principle, advantages, and maintenance requirements, you can make an informed decision when choosing an automatic garage door for your garage and ensure its proper operation and longevity.
